The pocket plate design, combined with the Nickel-cadmium (Ni-Cd) chemistry and valve regulated technology places the EnerSys PowerSafe VGL Ni-Cd Batteries in the lead with low maintenance batteries. The Ni-Cd technology provides exceptionally long life at extreme temperatures while the inherent extremely low maintenance feature is enhanced by the valve regulated design. Qualities which unquestionably make the Ni-Cd series of batteries an ideal choice for low rates of discharge over long periods.
The robust design provides an excellent resistance against electrical and mechanical stress, low risk of terminal degradation and a proven 20 plus year life. This combination along with proven use in service make the PowerSafe VGL battery the right choice for industrial applications, proven reliability and the highest safety integrity. The EnerSys PowerSafe VGL Ni-Cd batteries covers discharges of 1 hour to 100 hours.
EnerSys PowerSafe VGL Ni-Cd Batteries Features and Benefits
- Capacity range 12-1570Ah
- Single one piece container construction
- Ni-Cd pocket plate design
- Long storage and shelf life
- Wide operating temperature
- Low risk of terminal degradation
- Translucent plastic case for visible electrolyte level monitoring
- Proven 20 plus year service life
Construction
- Robust construction means low risk of terminal degradation
- Plate lugs are connected to post by bolting or welding
- Dilute potassium hydroxide electrolyte
- Felt separators insulate plates and improve recombination rates
- Dual post seal design minimizes carbon formation
- Single one piece container construction
- Flame arresting low Pressure Relief Valve (PRV)
Installation and Operation
- Extremely low watering requirements over normal service lifetime
- Low maintenance technology with recombination rates up to 90%
- Cells can be stored for long durations without damage
- Translucent case allows for electrolyte level verification
- Proven long service life with 20 plus years in stationary cycling operations
- Operating temperature: -22ºF (-30ºC) to 122ºF (50ºC)
- Recommended temperature: 32ºF (0ºC) to 104ºF (40ºC)
Models
Cell types available in the EnerSys PowerSafe VGL Ni-Cd battery series (number indicates AH Capacity).
VGL12
VGL20
VGL25
VGL35
VGL45
VGL50
VGL60
VGL70
VGL80
VGL100
VGL120
VGL135
VGL155
VGL175
VGL205
VGL225
VGL245
VGL275
VGL300
VGL330
VGL350
VGL275
VGL390
VGL420
VGL440
VGL500
VGL555
VGL585
VGL610
VGL645
VGL665
VGL705
VGL750
VGL795
VGL835
VGL890
VGL990
VGL1100
VGL1620
VGL1320
VGL1390
VGL1560
VGL1570
